GATE VALVE - API 602
Specification
DESIGN : API 602
WEDGES : SOLID
SEAT : RENEWABLE
STEM : RISING STEM
BACKSEAT : INTEGRAL
END CONNECTION : SOCKET WELD
: NPT - F
: SOCKET WELD X NPT - F
BONNET : BOLTED BONNET
TEMP. & PRESSURE : API 602 - ANSI #800
: ASME B16.34 - ANSI #900
: ASME B16.34 - ANSI #1500
TESTING : API 598
About this product
Gate Valve is a valve that opens by lifting a barrier out of the path of the fluid. Gate valves require very little space along the pipe axis and hardly restrict the flow of fluid when the gate is fully opened. The gate faces can be parallel but are most commonly wedge-shaped. Gate Valves are widely used water treatment, construction, oil, food & pharmaceuticals, chemistry; used as medium connection and truncation
download link hereTechnical Specification
